Network Preparation
- System Architecture
In a web environment, DeepFinder consists of an Agent and a Manager Server.
DeepFinder Agent: A security module that is installed directly on the web server it is protecting.
DeepFinder Manager Server: An integrated management server for Agents that allows administrators to configure security policies and monitor logs via a web browser.
- Network Connection and Port Information
For DeepFinder to operate correctly, communication between the following components is required according to firewall policies.
DeepFinder Manager Server: Must allow inbound traffic on the ports specified below to receive requests from the Agent and the administrator's PC.
DeepFinder Agent: Must be able to communicate outbound to send collected logs to the Manager Server.
Note
The default ports can be changed depending on the network environment.
| Connection Direction | Port | Function |
|---|---|---|
| DeepFinder Manager Server ← DeepFinder Agent (Web Server) | 10012~10020 | Security Policy Sync Security Log Transmission |
| DeepFinder Manager Server ← Administrator PC | 80, 443 | Security Policy Management View Logs & Dashboard |
